Shadow-Caster Multi-Zone Lighting Controller

Multi-Zone Lighting Controller - 4-Independent Zones

Shadow-Caster's "Zone Controller" allows for individual or simultaneous control of up to four separate lighting zones. Co-developed with WetSounds, the SCM-ZC gives the user the ability to quickly change the color and brightness of their lights, and allows for the synchronization of lights with music. Shadow-Net technology allows for the control of any RGB color-changing lights. It also allows integration with multi-functional displays and other audio visual equipment. The zone controller is perfect for total control of all of the lighting on a boat, RV or other automobiles.

The Multi-Zone Lighting Controller, is the first of its kind on the market. Co-Developed with Wet Sounds® the "Zone Controller" is an LED lighting controller perfect for marine and terrestrial applications. It is fully waterproof and capable of controlling all RGB and Shadow-NET enabled lights. Shadow-NET is a proprietary protocol developed by Shadow-Caster Lighting to communicate lighting color information via an embedded CAN (Control Area Network) bus.
Shadow-Caster's "Zone Controller" allows for individual or simultaneous control of up to four separate lighting zones. Quickly change color and brightness or synchronize the lights to music. Shadow-Net technology allows for control of lighting through integration into multi-functional displays and other audio visual equipment. The zone controller is perfect for total control of all of the lighting on a boat or yacht.
Small, sleek, and user friendly, the Zone Controller installs in a standard 3 inch gauge opening and includes a wiring harness and mounting hardware. The interface is backlit and uses tactile response switches. The Zone controller is the only waterproof, multi-functional RGB LED controller on the market today.

Specifications:

• Size: 3.625" outside diameter X 0.5" Height (92 x 13mm)

• UV stabilized polycarbonate cover with stainless steel bezel

• Machined aluminum rear housing

• IP65 controller and connector with 18" harness

• Supports up to 500W of LED lights

• Operating voltage: 10 - 30 volts DC

• 16 Illuminated silicone buttons

• 4 Independent zones

• Shadow-Net Enabled

• 1-Year Warranty

• Made in the USA

WARNING: This product can expose you to chemicals including LEAD which is known to the State of California to cause cancer, birth defects or other reproductive harm, and Urethane which is known to the State of California to cause cancer or other reproductive harm. For more information go to P65Warnings.ca.gov.

Manufacturer Part Number: SCM-ZC
